Ceti’s 5 Mpx Digi-Pad Microscope Tablet Camera is specially designed for microscopy applications. It comes with a high-definition 9.7″ colour LCD screen and is equipped with software that allows the user to preview an image, set the white balance, capture images and videos as well as having measurement and annotation capabilities. This modern microscope camera has an integral C-mount fitting, which can be connected to any microscope with a corresponding C-Mount or eyepiece adaptor.
5 Mpx Microscope’Tablet’ Camera is specially designed for microscopy applications. It comes with a high-definition 9.7″ colour LCD screen and is equipped with software that allows the user to preview an image, set the white balance, capture images and videos as well as having measurement and annotation capabilities.
LCD Panel: Panasonic IPS LCD screen (Super TFT)
Input Video Format: HDMI
Native Resolution: 1920 x 1080
Display Type: 16.9 Ratio, 11.6″ Active Matrix Super TFT LCD
Typical Contrast Ratio: 1000:1
Colours: 16.7 million
Viewing Angle (L/R/U/D): IPS Full View
Active Display Area; W x H (mm): 258 x 145
Pixel Pitch; W x H (mm): 0.134 x 0.134
Brightness: 350cd/sq. m
Backlight: LED backlight; 50,000 hours
Housing
Colour: Black
Dimensions; L x H x W (mm): 281 x 179 x 15.6
Weight (Kg): 0.4
Operating Environment
Operating Temperature (°C): -15 to +55
Operating Humidity (%RH): 10 to 90
Storage Humidity (%RH) : 5 to 90
Synchronization Range: 30 – 80 KHz Horizontal, 55 – 75 KHz Vertical
Power Supply: AC 110V – 220V/DC12V/1A
Power Consumption: Max. 12W
